Catalog

Search by vehicle

Category :

Transmission

Return

PEUGEOT/CITROEN DS4/C4 II D

Name: PEUGEOT/CITROEN DS4/C4 II D
Brand: Depa
SKU: 3084600
Price: 172.49 EUR
Availability: InStock

Ref : 3084600

Matching vehicles :

DS4 - 5008 - 308 - 3008

Family :TR

Non-compressed length : 990 mm

ABS on the vehicle : Yes

Length of the shaft (including bearing unit) : 400 mm

COTE ROUE

Type and position (snap ring/circlip) : Internal snap ring

Outer spline diameter : 27 mm

Number of splines on inner race : 39

Shoulder diameter : 59 mm

Nombre de cannelures extérieures : 25

Diamètre du bol : 96 mm

COTE BOITE

Seal seat diameter : 32 mm

Housing diameter : 79 mm

Number of external splines : 37

Length of the shaft (including bearing unit) : 400 mm

Diamètre des cannelures extérieures : 28 mm

Length of the gearbox output without seal seat : 86 mm

Sealing kit	COTE ROUE	5102
		T3070
		T3071
		5059
		5020
	COTE BOITE	6115
	COTE BOITE	6115
CV joint	COTE ROUE	JC54
	COTE ROUE	JC79
	COTE BOITE	PALCBMC82DT
	COTE BOITE	PALCBMC82DT
FIXATION	COTE ROUE	EC008
RESSORT	COTE BOITE	REC44
RESSORT	COTE BOITE	REC44
TRIAXE	COTE BOITE	TRIC44
TRIAXE	COTE BOITE	TRIC44
ROULEMENT	COTE BOITE	RLT005
ROULEMENT	COTE BOITE	RLT005

Equivalence to manufacturer references

PEUGEOT : 3273TT
PEUGEOT : 3273QR
PEUGEOT : 3273QQ
PEUGEOT : 3273TV
