Category :

Hydraulic power steering rack

Return
A1771_1.jpg 3D

HONDA CRV III

Ref : A1771

Matching vehicles :

CR V IV - CR V III

Family :CA

Presence of servotronic  : Without

Number of splines on the pinion  : 36

Tie rod thread size (rack side)  : M14 X 1,5

Fitting type  : Screw

Splined pinion  : Yes

Thread length  : 50 mm

Steering wheel position  : Left-hand drive

Manufacturer  : SHOWA

Total length  : 1265 mm

Tie rod thread size (tie rod end side)  : POSITION TYPE

INSTRUCTION MONTAGE

Oil flow rate for testing +/-0.5  : 5.82 L/min

Rack housing bore diameter  : 46.19 mm

Rack travel  : 145.0 mm

Lock to lock turns  : 3.75 tr

Diameter of the rack  : 26.00 mm

Boot kit for steering rack GAUCHE 4229 HONDA
T4229 NISSAN
DROITE 4232 HONDA
T4232

Equivalence to manufacturer references

  • HONDA : 53601SWYG02

  • HONDA : 53601SWCE02

  • HONDA : 53601SWYG01

  • HONDA : 53601SWYG03

  • HONDA : WE07712353

  • HONDA : WE07712530

  • HONDA : WE08901347

  • HONDA : WE08909928

  • HONDA : WE08913539
