Catalog

Search by vehicle

Category :

Transmission

Return

RENAULT LAGUNA RIGHT-SIDE

Name: RENAULT LAGUNA RIGHT-SIDE
Brand: Depa
SKU: 3025400
Price: 154.08 EUR
Availability: InStock

Ref : 3025400

Matching vehicles :

LAGUNA 1

Family :TR

Height : 16.5 mm

Compressed length : 795 mm

Length of the shaft (including bearing unit) : 270 mm

ABS on the vehicle : No

Thread pitch type : 20X150

Nut type : Lock

JOINT HOMOCINETIQUE COTE ROUE

Outer spline diameter : 25 mm

Housing diameter : 84 mm

Shoulder diameter : 56 mm

Number of external splines : 23

Number of splines on inner race : 25

Type and position (snap ring/circlip) : External snap ring

SOUFFLET COTE ROUE

Diameter (big) : 78 mm

Diameter (little) : 23 mm

Length : 79 mm

Number of grooves : 1

Type of material : Neoprene

Sealing kit	COTE ROUE	T3109
		T3025
		T3030
		5005
		5016
	COTE BOITE	5010
Fixation	COTE ROUE	EC005
CV joint	COTE ROUE	JR54
CV joint	COTE ROUE	JR541
Bearing		RLT018
Transmission		110026

Equivalence to manufacturer references

RENAULT : 7701349999
RENAULT : 7701352143
RENAULT : 7701352495
RENAULT : 7701352752
