Catalog

Search by vehicle

Category :

Transmission

Return

BMW REAR

Name: BMW REAR
Brand: Depa
SKU: 3347350
Price: 351.23 EUR
Availability: InStock

Ref : 3347350

Matching vehicles :

X5 E70 - X5 F15 F85 - X6 F16 / F86 - X5 (E70)

Family :TR

Compressed length : 810 mm

ABS on the vehicle : Yes

Thread pitch type : 27X150

Nut type : Washer

JOINT HOMOCINETIQUE COTE BOITE

Seal seat diameter : 43.45 mm

Outer spline diameter : 29.5 mm

Length of the gearbox output without seal seat : 75 mm

Number of external splines : 27

Number of splines on inner race : 28

JOINT HOMOCINETIQUE COTE ROUE

Diamètre des cannelures extérieures : 33 mm

Housing diameter : 93 mm

Shoulder diameter : 69 mm

Nombre de cannelures extérieures : 30

Nombre de cannelures sur la noix : 28

Observations : Threading length 18mm Ø27mm/Spline length on shoulder 61mm

Type and position (snap ring/circlip) : Internal snap ring

SOUFFLET COTE BOITE

Diameter (big) : 57 mm

Diameter (little) : 25 mm

Length : 69 mm

Type of material : Neoprene

SOUFFLET COTE ROUE

Diamètre (grand) : 57 mm

Diamètre (petit) : 25 mm

Longueur : 69 mm

Type de matière : NÉOPRÈNE

CV joint	COTE ROUE	JB7350
CV joint	COTE BOITE	CBMME7350
Sealing kit	COTE ROUE	5030
Sealing kit	COTE BOITE	5030
Fixation	COTE ROUE	EC032
Fixation		EC048

Equivalence to manufacturer references

BMW : 33207564127
BMW : 33208603102
BMW : 33208609838
