Search by vehicle
Category :
Transmission
Ref : 3381100
Matching vehicles :
S2000Family :TR
Height : 13.5 mm
Compressed length : 725 mm
ABS on the vehicle : Yes
Thread pitch type : 24X150
Nut type : Flat
JOINT HOMOCINETIQUE COTE BOITE
Mounting hole diameter : 10 mm
Outer diameter (boot side) : 135 mm
Flange thickness : 7 mm
Number of splines on inner race : 32
Number of mounting points : 6
SOUFFLET COTE BOITE
Diameter (big) : 85 mm
Diameter (little) : 38 mm
Length : 95 mm
Number of grooves : 2
Type of material : Neoprene
SOUFFLET COTE ROUE
Diamètre (grand) : 90 mm
Diamètre (petit) : 24 mm
Longueur : 90 mm
Nombre de gorges : 1
Type de matière : NÉOPRÈNE
| Fixation | COTE ROUE | EC008 |
|
| Sealing kit | COTE ROUE | 5026 |
|
| COTE BOITE | 6057 |
|
|
| CV joint | COTE BOITE | CBEH11 |
|
| ABS ring | COU057 |
|
Equivalence to manufacturer references
HONDA : 42310S2A951
