Category :
Transmission
Ref : 3565742
Matching vehicles :
PRIMERA IIFamily :TR
ABS on the vehicle : Yes
Length of the shaft (including bearing unit) : 310 mm
Compressed length : 940 mm
COTE ROUE
Outer spline diameter : 27.5 mm
Shoulder diameter : 56 mm
Observations : ABS 44 tooth/Ø87mm
Number of splines on inner race : 32
Number of external splines : 27
Type and position (snap ring/circlip) : Internal snap ring
Housing diameter : 92 mm
| CV joint | COTE ROUE | JN5444 |
|
| Sealing kit | COTE ROUE | 5020 |
|
| COTE BOITE | 6052 |
|
|
| 6175 |
|
||
| FIXATION | COTE ROUE | EC047 |
|
| COURONNE ABS | COU083 |
|
Equivalence to manufacturer references
NISSAN : 391005J010
NISSAN : 391002F210
